Ceiling Mount Pro Install series
An excellent choice for commercial and residential installs.
Indoor / outdoor housing, shorter install time, front side adjustment.
CMPI-525

5.25” poly cone woofer with rubber surround
1” titanium dome tweeter
Fully sealed ABS back box
Binding post speaker terminals
160 degree coverage

Power capacity: 40W/80W RMS/max
Frequency response: 80Hz~20KHz
SPL: 90dB
Transformer taps:
8ohm, 0.25W, 0.5W, 1W, 2.5W, 5W, 7.5W, 15W, 30W
25V/70V switch

Mounting depth: 5.5”
Required cutout: 8.2”
Overall frame diameter: 9.5"
Weight: 5lbs

MSRP: $144



5014070
CMPI-650

6.5” poly cone woofer with rubber surround
1” titanium dome tweeter
Fully sealed ABS back box
Binding post speaker terminals
160 degree coverage

Power capacity: 60W/120W RMS/max
Frequency response: 60Hz~20KHz
SPL: 90dB
Transformer taps:
8ohm, 0.25W, 0.5W, 1W, 2.5W, 5W, 7.5W, 15W, 30W
25V/70V switch

Mounting depth: 5.5”
Required cutout: 9.5”
Overall frame diameter: 11"
Weight: 6.1lbs

MSRP: $150



5014075
CMPI-800

8” poly cone woofer with rubber surround
1” titanium dome tweeter
Fully sealed ABS back box
Binding post speaker terminals
160 degree coverage

Power capacity: 90W/180W RMS/max
Frequency response: 40Hz~20KHz
SPL: 90dB
Transformer taps:
8ohm, 0.25W, 0.5W, 1W, 2.5W, 5W, 7.5W, 15W, 30W
25V/70V switch

Mounting depth: 5.5”
Required cutout: 11.25”
Overall frame diameter: 12.5"
Weight: 7.7lbs

MSRP: $168



5014080
